More Details
Image Sensor1/2.7" Progressive Scan CMOS
Min. IlluminationColor: 0.01 Lux @(F1.2; AGC ON), 0.028 Lux @(F2.0; AGC ON)
Shutter Speed1/3 s to 1/100,000 s
Slow ShutterYes
Day &NightIR Cut Filter
Wide Dynamic Range120 dB
Angle AdjustmentPan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360°
DNR3D DNR
Lens
Lens2.8/4/6 mm
Auto-IrisNo
ApertureF2.0
FocusFixed
FOV2.8 mm, horizontal FOV: 100°, vertical FOV: 74°, diagonal FOV: 130°,4 mm, horizontal field of view: 75°, vertical FOV: 55°, diagonal FOV: 98°,6 mm, horizontal field of view: 49°, vertical FOV: 37°, diagonal FOV: 60°
Lens MountM12
Illuminator
IR RangeUp to 30 m
Wavelength850nm
Video
Max. Resolution2560 × 1920
Main Stream50Hz:12.5fps (2560 × 1920), 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720),60Hz: 15fps (2560 × 1920), 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub Stream50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Video CompressionMain stream: H.265/H.264 ,Sub-stream: H.265/H.264/MJPEG
H.264 TypeBaseline Profile/Main Profile/High Profile
H.265 TypeMain Profile
Video Bit Rate32 Kbps to 8Mbps
Smart Feature-Set
Region Of InterestSupport 1 fixed region for main stream and sub-stream
Image EnhancementBLC/3D DNR
Image SettingSaturation, brightness, contrast and sharpness are adjustable via client software and web browser
Day/Night SwitchAuto/Scheduled/Day/Night
Network
Network StorageNAS (NFS,SMB/CIFS)
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, QoS, IPv6, UDP, Bonjour, 802.1x
APIONVIF(PROFILE S,PROFILE G), ISAPI
Simultaneous Live ViewUp to 6 channels
User/HostUp to 32 users,3 levels: Administrator, Operator and User
ClientiVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web BrowserIE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Alarm TriggerMotion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD error, HDD full
Interface
Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port
General
Firmware VersionV5.5.52
General FunctionHeartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Startup And Operating Conditions-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply12 VDC ± 25%,PoE: 802.3af, class 3
Power Consumption And Current12 VDC, 0.5 A, max. 5 W,PoE (802.3af, 36 to 57 V), 0.2 A to 0.1 A, max. 6.5 W
MaterialFront cover: metal, bracket: plastic, camera body: plastic
DimensionsCamera: Ø 70 mm × 172.7mm (2.7" × 6.8"),With package: 216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
WeightCamera: 300g (0.7 lb),With package: 550g (1.2 lb)
Interface ProtectionIP67
